ATEN 2-PORT USB 3.0 4K DISPLAYPORT DUAL DISPLAY KVMP SWITCH FOR ATC
Networking > Network Accessories
- Brand: ATEN
- Category: Network Switches
- SKU: CS1942ATC-AT-U
- MPN: CS1942ATC-AT-U
ATEN CS1942ATC-AT-U KVM switch Black
$2,878.78inc GST$2,503.29 ex GSTSave $151.01 off RRP
Available On OrderAsk us for ETA
1
Fast NZ-wide delivery 30-day easy returns Genuine product
Shipped to your region. Freight is calculated at checkout from live courier rates.
Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.
Collection available — we'll confirm pickup readiness after your order:
- 136 Cryers Road, East Tāmaki, Auckland 2013
Key Details
- Model:
- CS1942ATC-AT-U
- Part #:
- CS1942ATC-AT-U
- Brand:
- ATEN
ATEN 2-PORT USB 3.0 4K DISPLAYPORT DUAL DISPLAY KVMP SWITCH FOR ATC
The ATEN CS1942ATC 2-Port USB 3.0 4K DisplayPort Dual Display KVMP Switch for ATC is tailor-made for Air Traffic Control scenarios. It supports 2Kx2K resolution, making it perfect for radar monitoring, and also enables constant monitoring of flight information and mission-critical processes. Incorporating dual display capability, users can enjoy a wider screen and easy switch between the two DisplayPort systems.
The Zero-Second Switch function ensures nearly real-time switching without any black screens, providing air traffic controllers instant access to two USB / DisplayPort-interfaced dual display ATC computers for crucial operations. Port switching is flexible via pushbuttons, hotkeys, mouse, RS-232 commands, or an optional accessory the remote port selector.
With two lockable DC jacks for power redundancy, the CS1942ATC ensures uninterrupted operation and constant availability for mission-critical applications. It aims to greatly minimize or eliminate the risk of downtime. Patented ATEN technology – Video DynaSync™, and EDID expert™, combined with DisplayPort 1.2 and video resolutions up to 4K @ 60 Hz, it delivers optimized display resolution with exceptional detail and clarity in all conditions.
The CS1942ATC creates a safer environment and enhanced operational efficiency for Air traffic Control Towers, Approach Control Rooms, and Area Control Centers, specifically tailored the air traffic control industry.
The Zero-Second Switch function ensures nearly real-time switching without any black screens, providing air traffic controllers instant access to two USB / DisplayPort-interfaced dual display ATC computers for crucial operations. Port switching is flexible via pushbuttons, hotkeys, mouse, RS-232 commands, or an optional accessory the remote port selector.
With two lockable DC jacks for power redundancy, the CS1942ATC ensures uninterrupted operation and constant availability for mission-critical applications. It aims to greatly minimize or eliminate the risk of downtime. Patented ATEN technology – Video DynaSync™, and EDID expert™, combined with DisplayPort 1.2 and video resolutions up to 4K @ 60 Hz, it delivers optimized display resolution with exceptional detail and clarity in all conditions.
The CS1942ATC creates a safer environment and enhanced operational efficiency for Air traffic Control Towers, Approach Control Rooms, and Area Control Centers, specifically tailored the air traffic control industry.
Key features
- Number of computers controlled: 2
- Keyboard port type: USB
- Mouse port type: USB
- Video port type: DisplayPort
- VGA (D-Sub) ports quantity: 3
- DisplayPorts quantity: 4
- Console ports: 3.5mm headphone, 3.5mm mic, DisplayPort, USB A, VGA (D-Sub)
- Console USB ports quantity: 2
- Console DisplayPorts ports quantity: 2
- USB hub: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity: 2
- USB connector type: Micro-USB, USB Type-A
- Audio connections: Yes
- Headphone outputs: 2
- Number of microphone inputs: 2
- RJ-11 ports quantity: 1
- DC-in jack: Yes
- HD type: 4K Ultra HD
- Maximum resolution: 4096 x 2160 pixels
- Video bandwidth: 60 Hz
- Firmware upgradeable: Yes
- Product colour: Black
- Housing material: Metal
- LED indicators: Yes
- Push button: Yes
- Hot keys: Yes
- Built-in display: Yes
- Power source: DC
- Input voltage: 12 V
- Power consumption (typical): 17.8 W
