ATEN 2 PORT USB 3.0 4K DISPLAYPORT KVMP SWITCH WITH BUILD IN MST HUB
Networking > Network Accessories
- Brand: ATEN
- Category: Network Switches
- SKU: CS1922M-AT-U
- MPN: CS1922M-AT-U
ATEN CS1922M-AT-U KVM switch Black
$896.93inc GST$779.94 ex GSTSave $54.09 off RRP
Available On OrderAsk us for ETA
1
Fast NZ-wide delivery 30-day easy returns Genuine product
Shipped to your region. Freight is calculated at checkout from live courier rates.
Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.
Collection available — we'll confirm pickup readiness after your order:
- 136 Cryers Road, East Tāmaki, Auckland 2013
Key Details
- Model:
- CS1922M-AT-U
- Part #:
- CS1922M-AT-U
- Brand:
- ATEN
ATEN 2 PORT USB 3.0 4K DISPLAYPORT KVMP SWITCH WITH BUILD IN MST HUB
Incorporating the latest Multi-Stream Transport (MST) technology, the CS1922M 2-Port USB 3.0 4K DisplayPort MST KVMP™ Switch is the world's first DisplayPort KVM switch with a built-in MST hub. The CS1922M enables users to adopt two console displays from a single DisplayPort 1.2 video source, providing an extended desktop mode and splitter mode at resolutions up to 4K for multitasking across two displays while reducing bulky cable connections.
1x 2-Port USB 3.0 4K DisplayPort MST KVMP™ Switch
2x LIN5-20K1-K13G DisplayPort 1.2 Cables (1.5m/5ft)
2x LIN6-11C1-E12G USB Cables (USB 3.0-A to USB 3.0-B; 1.8m/6ft)
4x LIN5-0205-21DG/CD Audio Cables (1.8m/6ft)
1x LIN2-418K-E12G / 0AD8-8005-40MG Power Adapter
1x User Instructions
1x 2-Port USB 3.0 4K DisplayPort MST KVMP™ Switch
2x LIN5-20K1-K13G DisplayPort 1.2 Cables (1.5m/5ft)
2x LIN6-11C1-E12G USB Cables (USB 3.0-A to USB 3.0-B; 1.8m/6ft)
4x LIN5-0205-21DG/CD Audio Cables (1.8m/6ft)
1x LIN2-418K-E12G / 0AD8-8005-40MG Power Adapter
1x User Instructions
Key features
- Number of computers controlled: 2
- Keyboard port type: USB
- Mouse port type: USB
- Video port type: DisplayPort
- DisplayPorts quantity: 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity: 2
- Console ports: 3.5mm headphone, 3.5mm mic, DisplayPort, HDMI, USB A
- Console USB ports quantity: 2
- USB hub: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity: 2
- USB connector type: USB Type-A, USB Type-B
- Audio connections: Yes
- Headphone outputs: 4
- Number of microphone inputs: 4
- DC-in jack: Yes
- HD type: 4K Ultra HD
- Maximum resolution: 4096 x 2160 pixels
- Video bandwidth: 60 Hz
- Scan interval: 1,5,99 s
- Firmware upgradeable: Yes
- Product colour: Black
- Housing material: Metal, Plastic
- LED indicators: Yes
- Push button: Yes
- Hot keys: Yes
- Built-in display: No
- Power source: DC
- Input voltage: 5 V
- Power consumption (typical): 4.09 W
- Operating temperature (T-T): 0 - 50 °C
