ATEN 4 PORT DUAL OUTPUT HDMI SWITCH
Networking > Network Accessories
- Brand: ATEN
- Category: Network Switches
- SKU: VS482-AT-U
- MPN: VS482-AT-U
ATEN VS482-AT-U video switch HDMI
$566.55inc GST$492.65 ex GSTSave $97.57 off RRP
Available On OrderAsk us for ETA
1
Fast NZ-wide delivery 30-day easy returns Genuine product
Shipped to your region. Freight is calculated at checkout from live courier rates.
Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.
Collection available — we'll confirm pickup readiness after your order:
- 136 Cryers Road, East Tāmaki, Auckland 2013
Key Details
- Model:
- VS482-AT-U
- Part #:
- VS482-AT-U
- Brand:
- ATEN
ATEN 4 PORT DUAL OUTPUT HDMI SWITCH
With more and more HDMI devices entering the Home Theater market, the need for simultaneous access to different HDMI A/V sources is becoming increasingly important. Now, the VS482 4- Port Dual View HD Video Switch offers an easy and affordable way to add HDMI capabilities to your home theater system by allowing you to switch easily between up to four HDMI A/V sources that are connected to up to two HDMI displays.
The VS482 supports four HDMI video input sources and two HDMI output displays. It is designed for two HDTV or audio/video receiver (AVR) applications. The VS482 complies with HDMI standards, and is designed to support 3D content, as well as Audio Return Channel (ARC) function. The VS482 also offers instant switching and has OSD display controls for video, audio, system configuration and information.
The VS482 supports four HDMI video input sources and two HDMI output displays. It is designed for two HDTV or audio/video receiver (AVR) applications. The VS482 complies with HDMI standards, and is designed to support 3D content, as well as Audio Return Channel (ARC) function. The VS482 also offers instant switching and has OSD display controls for video, audio, system configuration and information.
Key features
- Video port type: HDMI
- HDMI ports quantity: 6
- HDMI in: 4
- Number of HDMI outputs: 2
- Audio (L/R) out: 2
- RS-232 ports: 1
- DC-in jack: Yes
- Material: Metal
- Product colour: Black
- HDCP: Yes
- Rack mounting: Yes
- Supported graphics resolutions: 1920 x 1080 (HD 1080)
- Supported video modes: 1080p
- Bandwidth: 6.75 Gbit/s
- Bandwidth: 225 MHz
- Maximum resolution: 1920 x 1080 pixels
- 3D: Yes
- HD type: Full HD
- Width: 437.2 mm
- Depth: 158.6 mm
- Height: 4 mm
- Weight: 2.17 kg
- Remote control included: Yes
- User guide: Yes
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
- Compliance certificates: RoHS
