ATEN TRUE 4K 8 PORT HDMI SWITCH
Networking > Network Accessories
- Brand: ATEN
- Category: Network Switches
- SKU: VS0801HB-AT-U
- MPN: VS0801HB-AT-U
ATEN VS0801HB-AT-U video switch HDMI
$671.66inc GST$584.05 ex GSTSave $122.95 off RRP
Available On OrderAsk us for ETA
1
Fast NZ-wide delivery 30-day easy returns Genuine product
Shipped to your region. Freight is calculated at checkout from live courier rates.
Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.
Collection available — we'll confirm pickup readiness after your order:
- 136 Cryers Road, East Tāmaki, Auckland 2013
Key Details
- Model:
- VS0801HB-AT-U
- Part #:
- VS0801HB-AT-U
- Brand:
- ATEN
ATEN TRUE 4K 8 PORT HDMI SWITCH
The ATEN VS0801HB is designed for applications that require the routing of 8 sources to one compatible display device. It supports video resolutions up to True 4K (4096 x 2160 @ 60Hz 4:4:4), data rates up to 18 Gbps, 3D, Deep Color up to 12-bit, and HD lossless audio formats. The VS0801HB features Auto Switching modes for auto port selection and Instant Switching for a smooth video transition between HDMI ports. Multiple convenient control options include front panel pushbuttons, bi-directional RS-232, IR, and auto switch, allowing for easy integration.
Engineered to meet today’s demand of True 4K signal transmission and user-oriented design, the ATEN VS0801HB is a powerful solution for a wide range of settings, such as home theater, meeting rooms, trade shows, and shopping centers.
Engineered to meet today’s demand of True 4K signal transmission and user-oriented design, the ATEN VS0801HB is a powerful solution for a wide range of settings, such as home theater, meeting rooms, trade shows, and shopping centers.
Key features
- Video port type: HDMI
- HDMI ports quantity: 8
- HDMI version: 2.0
- HDMI in: 8
- Number of HDMI outputs: 1
- RS-232 ports: 1
- DC-in jack: Yes
- Material: Metal
- Product colour: Black
- HDCP: Yes
- Maximum refresh rate: 60 Hz
- Maximum operating distance: 3 m
- Supported graphics resolutions: 1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160
- Bandwidth: 6 Gbit/s
- Bandwidth: 600 MHz
- Maximum resolution: 4096 x 2160 pixels
- 3D: Yes
- HD type: 4K Ultra HD
- Input impedance: 100 Ω
- Output impedance: 100 Ω
- AC adapter input voltage: 5.3 V
- Power consumption (typical): 3.73 W
- Width: 158.3 mm
- Depth: 437.2 mm
- Height: 44 mm
- Weight: 2.14 kg
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
